Track wheel 88mm Deep clincher Tubeless 700C carbon rims

Type:88mm Deep clincher tubeless carbon rims

Classical 88mm Deep Clincher carbon rims

88mm carbon Road Track Triathlon bike wheels

Braking side with 250°C high TG resin system

Toray T700 to make,UD/3K classical appearance

Wider U shape design,better for Flat bike

  • Item NO.:

    OS-TR88
  • Product Origin:

    China
  • Color:

    3K/UD/12K/1K Matte/glossy
  • Lead Time:

    A week
  • Order(MOQ):

    1

Product Model:700C Classical 88mm Deep Track bike carbon rims

88mm Deep carbon tubeless rims is the classic rims with 25mm wide U shape.Made of Full carbon Toray T700.The deeper rims are faster,better for aerodynamic and stiffness.88mm Deep rims comfort in Road triathlon and track bikes.if you are choosing the track carbon rims,this model is very OK.The rim used 250°C High TG resin system,better for the braking system.

Our Factory offer high quality carbon clincher rims with competitive price.Different braking surface can be made for you.

88mm Deep tubeless rim
88mm clincher carbon rim
clincher carbon wheel

Features:

1.High TG resin temperature with 250°C brake track from braking in road bicycle clincher wheels.

2.Full Toray T700 & T800 carbon fiber, Super lightweight rims,best strength to weight ratio with no expense spared.
3.The new style of 88mm Deep clincher rims have faster braking heat elimination.

4.Wide U sahpe design,classical standard model for track Triathlon bike wheels.

5.We offer decal and painting service for OEM your brands.

6.We can customized Different patterns of brake surface .

7.The manufature for High quality carbon clincher carbon rims .

8. 5 years warranty


Specification:

Model

TR45C-25

TR45C-27

Size

700C

700C

Sectional Drawing

700C track wheel

Road track carbon rim

Material

Toray T700 & T800

Toray T700 & T800

Depth

88mm

88mm

Wide

23mm

25mm

Weight

730+/-15g

730+/-15g

Appearance

3K/UD OrCustomized

3K/UD OrCustomized

Spokes holes

18-36#Customized

18-36#Customized

ERD

464mm

464mm

Assembly Hole Dia.

7.6mm

7.6mm

Spokes hole Dia

4.2mm

4.2mm

Valve hole Dia.

6.6mm

6.6mm

Flatness

<0.25mm

<0.25mm

Roundness

<0.5mm

<0.5mm

Max Spoke Tension

>300kg

>300kg

Ultimate Strength

>300kg

>300kg

Torsion Strength

>50kg

>50kg

Tire Size Recommended

700*21-25c

700*25-28c

Max Tire Pressure

125psi/8.6bar

125psi/8.6bar


Factory production manufacture

Factory carbon rim


100% Quality Inspection:

Our rims are made of 100% Full carbon fiber material to ensure the high quality of the goods. Each carbon rim by us has its unique serial ID number, which follow every step of the product. And confirm every rim to ensure the best after-sale service.

5 years warranty:

The warranty covers five years form the initial pruchase of the product.

The warranty applies to the original purchaser and the assignmnet is invalid.

The warranty requires proof of pruchase,product serial number and defect picture.

Please keep your proof of purchase for any future warranty problems.

This warranty does not cover:

1. Normal wear and tear and depreciation.

2. Any man-made damage caused by accident,misuse,etc.

3. Improper installation,maintenance or other conduct by an unauthorized technician.
